Commercial Cinema Solutions
cinema series 3 way
For the rear-view Echora Acoustics Commercial Cinema Screen Speaker, you can use these professional specifications:
ECHORA ACOUSTICS ECA-5974
Premium 4-Way Commercial Cinema Screen Speaker
Description
The ECA-5974 is a high-performance 4-way cinema screen speaker designed for medium to large commercial auditoriums. Engineered for exceptional dialogue clarity, dynamic impact, and uniform coverage, it provides a truly immersive cinematic experience, making it ideal for various audio installations with high SPL capability and low distortion.
Key Features
• 4-Way Cinema Screen Speaker System
• Constant Directivity Horn Technology
• High Output Compression Drivers
• Precision Tuned Passive / Active Crossover Options
• Excellent Speech Intelligibility
• Wide Audience Coverage
• Commercial Grade Birch Plywood Cabinet
• Durable Black Textured Finish
• Dolby Atmos Compatible
Technical Specifications
Frequency Response
32Hz – 19kHz (±3dB)
Sensitivity
108dB (1W/1m)
Maximum SPL
138dB Continuous
144dB Peak
Nominal Impedance
4 Ohms
Power Handling
2000W AES
4000W Program
Coverage Pattern
90° Horizontal × 40° Vertical
Driver Configuration
Ultra High Frequency
• 1 × 1.75" Titanium Compression Driver
High Frequency
• 1 × 4" Compression Driver
Mid Frequency
• 2 × 6.5" High Efficiency Midrange Drivers
Low Frequency
• 4 × 15" High Excursion Cinema Woofers
Enclosure
Construction
• 18mm Premium Birch Plywood
Finish
• Black Polyurea Textured Coating
Dimensions (H × W × D)
• 2550 × 850 × 460 mm
Weight
• 145 kg
Applications
• Commercial Cinemas
• Multiplex Auditoriums
• Premium Large Format Screens
• Dolby Atmos Theatres
• Luxury Screening Rooms
Brand
ECHORA ACOUSTICS
Designed & Engineered by Echora Acoustics
Crafted in India
This specification sheet aligns with the style and presentation used by premium cinema brands and is tailored to fit perfectly within your commercial cinema solutions catalogue.
